Lenovo ideapad 2in 1 11

The Lenovo ideapad 2in 1 11 is a convertible laptop computer with a 360-degree rotating display, allowing it to operate as a traditional notebook or touchscreen tablet. It features a multi-touch LCD screen, built-in keyboard, touchpad, integrated camera, microphone, wireless LAN connectivity, and stereo speakers.

The computer supports four operating positions: Notebook Mode, Stand Mode, Tablet Mode, and Tent Mode. The display can rotate through 360 degrees, and the keyboard and touchpad are automatically disabled when the screen is opened beyond approximately 190 degrees.

The ideapad 2in 1 11 includes USB connections, an HDMI output, an RJ-45 Ethernet port, a combo audio jack, and a memory card reader. An integrated rechargeable battery provides portable operation, while the AC power adapter supplies external power.

The keyboard includes hotkeys for adjusting volume, brightness, camera operation, Airplane Mode, and display output. Its touchscreen supports tapping, scrolling, zooming, rotating objects, and accessing Windows features through edge gestures.

The laptop is designed to work with Windows 10, including the Start menu, virtual desktops, wireless networking, Sleep mode, and system recovery. A dedicated Novo button provides access to BIOS Setup, the boot menu, and system recovery functions.

Technical Specifications

Some features may vary according to the computer’s configuration.

Parts and Components

The Lenovo ideapad 2in 1 11 includes hardware components positioned around the display, keyboard, sides, and bottom of the computer.

Top Components

Integrated Camera

The camera supports video communication and photography through compatible software.

It can be enabled or disabled using the corresponding keyboard hotkey.

Built-In Microphone

The microphone captures audio for video conferencing, voice narration, and recording applications.

A keyboard hotkey provides microphone control.

Wireless LAN Antennas

The integrated antennas connect to the wireless LAN adapter to transmit and receive radio signals.

Multi-Touch Display

The LCD display uses LED backlighting and supports direct touchscreen interaction.

The display can rotate through 360 degrees to accommodate different computer operating positions.

Touchpad

The laptop includes a one-piece multi-touch ClickPad.

To move the pointer, slide a fingertip across the touchpad in the required direction.

Press F6 to enable or disable the touchpad.

Left-Side Ports and Connections

The left side includes the power connector, charging indicator, USB connection, HDMI port, and memory card reader.

Left-Side Component Guide

AC Power Adapter Jack

The power adapter connects to the dedicated AC power jack.

This connection supplies electrical power to the computer and charges the battery.

USB 3.0 Port

The USB 3.0 connection supports compatible USB devices and accessories.

A USB port identified by a charging symbol also supports charging an external USB device while the computer is turned off, provided the laptop battery contains more than 20% charge.

HDMI Port

The HDMI connector supports compatible external displays, including televisions and monitors with HDMI input.

Memory Card Reader

The memory card reader accepts compatible removable memory cards for data storage and transfer.

Right-Side Ports and Controls

The right side contains the power controls, system startup button, audio connection, USB ports, and Ethernet port.

Right-Side Component Guide

Power Button

Press the Power button to turn on the computer.

The button can also be used for Sleep mode and resuming the computer, according to the Windows power configuration.

Novo Button

The Novo button is used when the computer is turned off.

It provides access to:

• Lenovo OneKey Recovery startup functions
• BIOS Setup Utility
• Boot Menu

Combo Audio Jack

The combo audio jack supports compatible headsets.

Important: Conventional standalone microphones are not supported through this connector.

Recording may also be unavailable with certain third-party headsets because of differences in industry standards.

RJ-45 Ethernet Port

The RJ-45 connection supports wired networking through an Ethernet cable.

The port includes a hinged cover that must be pressed down gently when inserting the cable.

Bottom Components

The bottom of the computer contains the built-in speakers.

These speakers provide audio output for Windows, multimedia applications, and other supported software.

Battery and Power Status Indicators

The laptop uses white and amber indicator lights to show battery and power conditions.

Battery Indicator Light Guide

Charging Indicator Behavior

When the battery reaches 20% charge, the slowly blinking amber indicator changes to white.

When the battery reaches 80%, the slowly blinking white indicator stops blinking.

Charging continues until the battery becomes fully charged.

Power Indicator Light Guide

Important Safety Instructions

Before operating the computer, read the Lenovo Safety and General Information Guide supplied with the product.

Display and Hinge Safety

When closing the display, make sure no pens or other objects remain between the screen and keyboard.

Objects trapped between these surfaces may damage the display panel.

Important: Do not rotate the screen using excessive force. Doing so may damage the display panel or hinges.

Moving the Computer in Sleep Mode

Before moving the laptop while it is entering Sleep mode, wait until the Power indicator starts blinking.

Moving the computer while the hard disk is spinning may damage the drive and cause data loss.

External Device Precautions

Do not connect or disconnect non-USB external device cables while the computer is powered on.

Doing so may damage the computer.

External devices with high power requirements, such as certain USB optical drives, should use their own power adapters.

Safe Recovery and Data Protection

System recovery can change or remove applications, settings, and personal files depending on the selected recovery option.

The appropriate recovery method must be selected carefully before starting the reset process.

Before First Use

The computer may require Windows configuration when it is turned on for the first time.

Initial Preparation

1. Position the computer on a suitable surface.
2. Connect the AC power adapter.
3. Turn on the computer using the Power button.
4. Follow the Windows setup instructions.

Windows 10 First-Time Setup

The setup process may include:

• Accepting the end-user license agreement
• Configuring the internet connection
• Registering the operating system
• Creating a user account

Follow the on-screen instructions to complete the required steps.

How to Use the Keyboard

The Lenovo ideapad 2in 1 11 includes function keys and hotkeys for controlling common computer features.

Function Key Combinations

Hold the Fn key while pressing the required function key.

Keyboard Hotkey Functions

Changing Hotkey Behavior

The hotkey function can be enabled or disabled using Lenovo Setting.

The behavior of individual function keys depends on the selected hotkey configuration.

Convertible Laptop Operating Modes

The ideapad 2in 1 11 display rotates through 360 degrees.

Four operating positions are supported.

Notebook Mode

Notebook Mode is intended for conventional laptop tasks that require keyboard and pointer input.

Typical activities include:

• Creating documents
• Writing emails
• Working with keyboard-based applications

The display remains positioned above the keyboard.

Stand Mode (Theater Mode)

Stand Mode positions the display for viewing content with little or no keyboard interaction.

This arrangement is suitable for watching videos and viewing photographs.

Tablet Mode

Tablet Mode allows the computer to be operated through direct touchscreen interaction.

The display is rotated fully backward so that the computer can be held or positioned like a tablet.

Tablet Mode is suitable for tasks such as:

• Browsing the internet
• Playing touchscreen games
• Using touch-based applications

Tent Mode (Presentation Mode)

Tent Mode positions the computer in an inverted V shape.

This arrangement is suitable for:

• Displaying graphs
• Viewing presentations
• Showing PowerPoint slides
• Applications requiring limited touchscreen interaction

Operating Mode Comparison

Keyboard and Touchpad Locking

The keyboard and touchpad are automatically locked when the display is opened beyond approximately 190 degrees.

This prevents accidental keyboard or touchpad input while the computer is being used in convertible positions.

Screen Orientation

The computer supports automatic display orientation changes.

Depending on how the device is held, the screen switches between:

• Landscape orientation
• Portrait orientation

This feature allows the display to adapt when the computer is rotated.

Windows 10 Start Menu

Windows 10 provides a Start menu for opening applications and managing settings.

How to Open the Start Menu

Use either method:

1. Press the Windows key.
2. Select Start in the lower-left corner of the desktop.

Main Windows 10 Controls

How to Open Settings

1. Open the Start menu.
2. Select Settings.
3. Choose the required settings category.

The Settings application also contains a search box for finding individual options.

How to Pin an App to Start

1. Open Start.
2. Find the application in the apps list.
3. Right-click the application.
4. Select Pin to Start.

An application can also be dragged from the apps list into the Start menu.

Sleep Mode and Shutdown Instructions

The computer provides Sleep mode for short periods of inactivity and Shutdown for longer periods when it will not be used.

How to Put the Computer to Sleep

Use any of the following methods:

• Close the display lid.
• Press the Power button.
• Open Start > Power > Sleep.

In Sleep mode, the current session can be resumed without completing a full startup.

How to Wake the Computer

Use either method:

• Press any keyboard key while in Notebook Mode.
• Press the Power button.

How to Shut Down the Computer

Method 1

1. Open Start.
2. Select Power.
3. Choose Shut down.

Method 2

1. Right-click or press and hold the Start button.
2. Select Shut down or sign out.
3. Select Shut down.

Windows Task View and Virtual Desktops

Windows 10 includes Task View for managing open applications and multiple desktops.

How to Open Task View

Use any of the following methods:

• Select the Task View button on the taskbar.
• Press Windows + Tab.
• Swipe inward from the left edge of the touchscreen.

Creating a Virtual Desktop

1. Open Task View.
2. Select New desktop.

Alternatively, press:

Windows + Ctrl + D

Switching Between Virtual Desktops

Open Task View and select the required desktop.

The following shortcuts can also be used:

How to Connect to WiFi

The computer includes wireless LAN connectivity.

Step 1: Enable Wireless Networking

Press F7 to disable Airplane Mode.

Step 2: Open Network Settings

Select the network icon in the lower-right corner of the Windows taskbar.

Windows displays the available wireless networks.

Step 3: Select a Network

1. Choose the required network.
2. Select Connect.
3. Enter the security key or passphrase if requested.

If the network password is unavailable, contact the network administrator or internet service provider.

How to Connect USB Devices

The computer supports compatible USB devices through its USB Type-A connections.

Connecting a USB Device

1. Locate an available USB port.
2. Insert the USB device’s Type-A connector.
3. Allow Windows to detect the device.
4. Wait for the required driver installation if necessary.

Windows usually installs drivers automatically when a device is connected for the first time.

Some devices require their drivers to be installed before connecting the hardware.

Safely Removing USB Storage

Before disconnecting a USB storage device:

1. Make sure all data transfers have finished.
2. Select Safely Remove Hardware and Eject Media in the Windows notification area.
3. Eject the device.
4. Disconnect the USB connector.

USB Devices with External Power

If a USB device uses its own power cord, connect that device to its power supply before attaching it to the laptop.

Otherwise, the device may not be recognized.

Connecting an Ethernet Network Cable

The laptop includes an RJ-45 connector for wired networking.

Ethernet Connection Instructions

1. Locate the RJ-45 port on the right side.
2. Hold the Ethernet cable connector against the port cover.
3. Press the hinged cover downward gently.
4. Insert the network cable into the port.

For network software configuration, consult the internet service provider.

Connecting an External Monitor or Television

The HDMI connector supports compatible external display devices.

Connecting Through HDMI

1. Locate the HDMI port on the left side.
2. Connect a compatible HDMI cable.
3. Connect the opposite end to the external monitor or television.
4. Use the keyboard’s display-switching hotkey to select the required display output.

Using Memory Cards

The memory card reader accepts several removable storage card types.

Supported Memory Cards

Only one memory card may be inserted at a time.

How to Insert a Memory Card

Insert the card into the slot until it reaches the bottom.

How to Remove a Memory Card

1. Disable the card using Windows Safely Remove Hardware and Eject Media.
2. Gently pull the memory card out.

Safely removing the card helps prevent data corruption.

Touchscreen Gestures

The multi-touch screen supports direct input using one or more fingertips.

Touchscreen Gesture Guide

Tap Gesture

Tap an item once to select it or perform its assigned action.

This gesture performs the same general function as a left mouse click.

Press and Hold Gesture

Press and hold an item to display additional information or open a menu with more options.

This is similar to right-clicking with a mouse.

Pinch and Spread Gestures

Move two fingers together to zoom out.

Move them apart to zoom in.

The feature works in compatible applications, including images and maps.

Rotate Gesture

Place two or more fingers on a supported object and rotate the fingers.

Not all applications support rotation.

Slide Gesture

Drag a finger across the screen to scroll through pages or lists.

Sliding can also move objects or support writing and drawing in compatible applications.

Lenovo Novo Button and BIOS Setup

The Novo button provides access to system startup and recovery functions.

The computer must be turned off before the Novo button is used.

Novo Button Functions

How to Open BIOS Setup

1. Shut down the computer.
2. Press the Novo button.
3. Select BIOS Setup.

BIOS Setup Functions

The BIOS Setup Utility provides basic computer information and settings for:

• Boot devices
• Security
• Hardware modes
• Other system preferences

How to Change Boot Mode

Selected configurations support two boot modes:

To change the boot mode:

1. Open BIOS Setup through the Novo button.
2. Locate the Boot menu.
3. Select UEFI First or Legacy Support as required.

Legacy Support is required for installing certain older Windows operating systems on supported configurations.

Windows 10 Recovery System

Windows 10 includes the Reset this PC recovery feature.

It allows the operating system to be restored using different recovery options.

Reset This PC Options

How to Reset Windows Using the Novo Button

1. Turn off the computer.
2. Press the Novo button.
3. Select System Recovery.
4. Select Troubleshoot.
5. Choose Reset this PC.
6. Select the required recovery option.
7. Follow the on-screen instructions.

How to Reset Windows Through Settings

1. Open Windows Settings.
2. Select Update & Security.
3. Open Recovery.
4. Find Reset this PC.
5. Select Start.
6. Choose the required recovery option.

The choice between retaining files and removing everything must be made carefully.

Lenovo Preinstalled Software and Drivers

Some Lenovo computers include a Windows operating system and applications installed at the factory.

Checking Whether Windows Was Preinstalled

The sales package includes a configuration label.

Check the text next to OS.

If the text includes Windows or WIN, the computer was supplied with a Lenovo-preinstalled Windows operating system.

Preinstalled Applications

Factory-installed software may include:

• Lenovo-developed applications
• Software from third-party vendors
• Trial applications

Some software requires a purchased license after the trial period expires.

Finding Device Drivers

If the computer was supplied with Windows, check the driver installation programs on the C partition.

Additional drivers can be downloaded from:

http://support.lenovo.com

Windows Compact-Enabled Storage

Some Windows installations use Compact technology.

This technology may be enabled on Windows 10 computers that use SSD or eMMC-only storage configurations.

How to Check Compact Status

1. Right-click the Start button.
2. Select Disk Management.
3. Inspect the Windows partition.

If the partition is labeled Compact, the installed version of Windows uses Compact technology.

Why Removing Software May Not Free Much Storage

On Compact-enabled systems, many files required by preinstalled software are stored in the Recovery Partition.

Removing an application through Windows may not remove those files.

As a result, available disk space may not increase significantly after uninstalling some preinstalled applications.

Troubleshooting Guide

The following troubleshooting procedures cover the display, Sleep mode, battery operation, audio, recovery, and external devices.

Common Problems and Solutions

Computer Does Not Start

If the screen remains blank after the Power button is pressed:

1. Confirm that the AC adapter is connected to the computer.
2. Check that the adapter is connected to a working electrical outlet.
3. Press the Power button again to confirm that the computer is on.

If the screen remains blank, the computer requires service.

White Cursor on a Blank Screen

If only a white cursor appears at startup, restore the Windows environment using Reset this PC.

If the condition remains after recovery, the computer requires service.

Computer Does Not Wake from Sleep

If the computer fails to resume:

1. Connect the AC power adapter.
2. Press the Power button.
3. If the system remains unresponsive, follow the reset procedure below.

How to Reset an Unresponsive Computer

1. Press and hold the Power button for eight seconds or longer.
2. If the computer does not respond, disconnect the AC power adapter.

Important: Unsaved data may be lost when the computer is forcibly reset.

Blank or Distorted Display

If the display is blank but the battery indicator shows power, press F12 to increase brightness.

If the power indicator is blinking, press Power to resume from Sleep mode.

For an unreadable or distorted display, check:

• Screen resolution
• Color quality
• Monitor type

No Sound from the Speakers

If the volume is turned up but no sound is heard:

1. Check that Mute is turned off.
2. Confirm that the combo audio jack is not being used.
3. Make sure the built-in speakers are selected as the playback device.

Unexpected Battery Shutdown

If the computer switches off before the battery indicator shows empty, recharge the battery.

The same procedure applies when the computer continues operating after the battery indicator reports an empty battery.

External Device Problems

When external devices are not working correctly:

• Avoid connecting or disconnecting non-USB device cables while the computer is powered on.
• Provide an external power adapter for devices with high power requirements.
• Follow the device manufacturer’s connection instructions.

Computer Freezes During Network Activity

The computer may become unresponsive if it enters Sleep mode during a communication operation.

Disable the Sleep timer while performing network operations that may be interrupted by Sleep mode.

Warranty Information

Warranty coverage for the Lenovo ideapad 2in 1 11 depends on the applicable Lenovo warranty terms and the computer’s serial number.

The warranty status can be checked through Lenovo Support.

How to Check Warranty Status

1. Open http://support.lenovo.com.
2. Enter the computer’s serial number.
3. Review the warranty information provided for the device.

Customer Support Information

Lenovo provides support resources for drivers, operating system questions, device problems, warranty information, and regulatory documentation.

Finding the Safety Guide

The Lenovo Safety and General Information Guide can be accessed through the Lenovo Companion or Lenovo PC Manager application on supported installations.

It can also be downloaded from Lenovo Support.

Contacting Customer Service

For assistance with hardware problems, operating system issues, or service requests, consult the customer support information in the Lenovo Safety and General Information Guide.

Frequently Asked Questions

1. How do I enter BIOS on the Lenovo ideapad 2in 1 11?

Turn off the computer, press the Novo button, and select BIOS Setup. The BIOS Setup Utility provides options for boot devices, security, hardware modes, and other supported settings.

2. How do I switch the Lenovo ideapad 2in 1 11 to Tablet Mode?

Rotate the display backward through 360 degrees. The keyboard and touchpad are automatically disabled when the display passes approximately 190 degrees, allowing the computer to be operated through its touchscreen.

3. What are the four operating modes of the Lenovo ideapad 2in 1 11?

The computer supports Notebook, Stand, Tablet, and Tent modes. Notebook Mode is suitable for typing, Stand Mode for watching content, Tablet Mode for touch interaction, and Tent Mode for presentations or viewing information.

4. How do I connect the Lenovo ideapad 2in 1 11 to WiFi?

Press F7 to disable Airplane Mode. Select the network icon on the Windows taskbar, choose the required wireless network, and select Connect. Enter the network password if prompted.

5. What does a blinking amber battery light mean?

A slowly blinking amber light means the battery is charging and has less than 20% capacity. A quickly blinking amber light while discharging means the remaining battery level is below 5%.

6. How do I reset Windows 10 on the Lenovo ideapad 2in 1 11?

Open Settings > Update & Security > Recovery and select Reset this PC. Alternatively, shut down the computer, press the Novo button, and select System Recovery > Troubleshoot > Reset this PC. Choose Keep My Files or Remove Everything according to the required recovery action.

7. What should I do if the Lenovo ideapad 2in 1 11 screen stays black?

Check that the computer is connected to a working power source and is turned on. Press F12 to increase brightness and press the Power button if the computer is in Sleep mode. If the display remains blank, Lenovo recommends professional service.

8. How do I restart the Lenovo ideapad 2in 1 11 if it freezes?

Press and hold the Power button for at least eight seconds. If the computer still does not respond, disconnect the AC power adapter. This forced shutdown may cause unsaved data to be lost.
