BELLA PRO Barista Elite Espresso Station 90210

The BELLA PRO Barista Elite Espresso Station is a countertop espresso maker with programmable single- and double-shot extraction, a steam wand for textured milk, hot-water dispensing, a removable 57 oz water tank, cup-warming plate and two-spout portafilter. The machine automatically dispenses preset espresso volumes and also allows the single- and double-shot volumes to be customized. Bella-Pro-Barista-Elite-Espress… Bella-Pro-Barista-Elite-Espress…

The standard single shot is approximately 1.35 oz, while the standard double shot is approximately 2.7 oz. The water tank holds up to 1.7 L / 57 oz, and the appliance connects to a 120V AC outlet. Bella-Pro-Barista-Elite-Espress… Bella-Pro-Barista-Elite-Espress…

The official manual also covers initial pump priming, adjusting shot volume, frothing milk, switching from steam back to espresso, cleaning the steam wand and portafilter, descaling, storage, troubleshooting and espresso drink recipes.

Product Overview

Espresso quality depends on several factors working together. According to the manual, temperature, fresh coffee, grind size, coffee dose, tamping pressure, clean filter baskets and a clean steam wand can all affect extraction.

The machine pre-infuses the grounds using low, steady water pressure before extraction and automatically dispenses the selected shot volume. Bella-Pro-Barista-Elite-Espress…

For more consistent results, the manual recommends keeping the following variables as consistent as possible:

• Coffee freshness
• Roast quality
• Grind size
• Ground-coffee dose
• Tamping pressure
• Water temperature
• Cup and portafilter temperature
• Filter-basket cleanliness

Parts and Components

The product diagram on page 6 identifies the main parts of the Barista Elite Espresso Station. Bella-Pro-Barista-Elite-Espress…

The page 6 illustration shows the removable water tank at the rear, the steam wand on the right side, the portafilter below the brew head and the removable drip tray under the cup area.

Control Panel and Button Guide

The control panel uses four buttons. Bella-Pro-Barista-Elite-Espress…

Power Button Lights

When the POWER button is pressed:

1. The Single and Double buttons begin flashing.
2. The machine heats.
3. Once operating temperature is reached, all four control-panel buttons illuminate. Bella-Pro-Barista-Elite-Espress…

Steam Button Light

After STEAM is pressed:

• The Steam button flashes while the machine heats.
• The button becomes solid when steam temperature has been reached. Bella-Pro-Barista-Elite-Espress…

Single Shot Button

Press once to start the factory-set 1.35 oz single-shot extraction.

Press and hold for approximately 3 seconds to program a different single-shot volume. Bella-Pro-Barista-Elite-Espress…

Double Shot Button

Press once for the factory-set 2.7 oz double shot.

Press and hold for approximately 3 seconds to change the stored double-shot volume. Bella-Pro-Barista-Elite-Espress…

Main Operating Specifications

These operating values are stated across the control, brewing, programming and maintenance sections of the manual. Bella-Pro-Barista-Elite-Espress… Bella-Pro-Barista-Elite-Espress… Bella-Pro-Barista-Elite-Espress…

Important Safety Instructions

The espresso maker produces hot water and steam under pressure, so burn and scalding precautions are important.

The manual instructs owners to:

• Read all instructions before use.
• Avoid touching hot surfaces directly.
• Never leave the pressurized machine unattended while operating.
• Keep the appliance, plug and power cord out of water and other liquids.
• Unplug the appliance when it is not being used and before cleaning.
• Let the machine cool before removing or installing parts.
• Stop using the appliance if the cord or plug is damaged or the machine malfunctions.
• Use only accessories recommended for this appliance.
• Do not use the espresso maker outdoors.
• Keep the power cord away from hot surfaces and countertop edges.
• Keep the machine away from hot burners and ovens.
• Never operate the espresso maker without water.
• Release pressure through the steam wand before removing the cup or filter basket.
• Do not open the brew chamber during brewing.
• Put the machine into standby and switch it off before unplugging it. Bella-Pro-Barista-Elite-Espress…

Hot Water and Steam Safety

The appliance generates heat and escaping steam.

It should:

• Sit on a heat-resistant surface.
• Remain at least 4 inches away from walls and nearby objects while running.
• Be allowed to cool before more water is added.
• Be moved only after it has cooled completely. Bella-Pro-Barista-Elite-Espress…

Use Water Only

The water tank should contain fresh, cool water only, except when preparing the vinegar-and-water mixture described in the descaling procedure.

Warm water, food products or other liquids can damage the espresso maker. Bella-Pro-Barista-Elite-Espress…

Polarized Plug

The appliance has a polarized plug.

If it does not fit fully into the electrical outlet:

1. Reverse the plug.
2. Try the outlet again.
3. If it still does not fit, contact a qualified electrician.

The plug should not be modified. Bella-Pro-Barista-Elite-Espress…

Extension Cord Safety

If an extension cord is used:

• Its electrical rating must be at least equal to the appliance’s rating.
• If grounding is required, use a three-wire grounding cord.
• Route the cord so it does not hang over the counter or table where it could be pulled or tripped over. Bella-Pro-Barista-Elite-Espress…

Countertop Protection

The manual recommends placing a non-plastic coaster or placemat between the appliance and finished furniture or countertops.

This reduces the possibility of plasticizers affecting the finish and causing stains, darkening or permanent marks. Bella-Pro-Barista-Elite-Espress…

Before First Use

Before making the first espresso, the espresso maker should be assembled, filled, pre-cleaned and primed.

1. Remove Packaging

Take away all packaging materials and make sure the espresso maker is unplugged. Bella-Pro-Barista-Elite-Espress…

2. Install the Drip Tray

Slide the removable drip tray into position and place the drip plate on top. Bella-Pro-Barista-Elite-Espress…

3. Fill the Water Tank

The tank can be filled while installed or removed from the rear of the appliance.

Fill it with cold water to the:

MAX — 1.7 L mark

Then reinstall the tank securely and close its lid. Bella-Pro-Barista-Elite-Espress…

How to Prime and Pre-Clean the Espresso Maker

The pump should be primed before the first espresso is made.

1. Place the machine on a level surface near a sink.
2. Install an empty 2-cup filter basket into the portafilter.
3. Lock the empty portafilter into the brew head.
4. Place a wide container under the two portafilter spouts.
5. Position the steam wand in a suitable container or frothing jug.
6. Place another container beneath the hot-water outlet.
7. Plug the machine into a 120V AC outlet.
8. Press POWER.
9. Wait until all four buttons illuminate.
10. Press STEAM.
11. Wait until the steam temperature is reached.
12. Turn the function dial to STEAM.
13. Let hot steam purge the line.
14. After no more than 90 seconds, return the dial to STANDBY.
15. Use the Double Shot button repeatedly to pump hot water through the system until the water tank has been purged. Bella-Pro-Barista-Elite-Espress… Bella-Pro-Barista-Elite-Espress…

After this procedure, the pump is primed and the internal system has been rinsed.

How to Pull an Espresso Shot

The manual recommends warming the cup and portafilter before adding coffee.

Step 1: Preheat the Cup

Place the empty espresso cup on the heated warming plate before extraction. Bella-Pro-Barista-Elite-Espress…

Step 2: Run a Blank Shot

Before brewing coffee, run a water-only shot through the portafilter.

This warms:

• The brew head
• Portafilter
• Filter basket
• Serving cup

The manual repeats this recommendation before brewing espresso. Bella-Pro-Barista-Elite-Espress… Bella-Pro-Barista-Elite-Espress…

Step 3: Check the Water Tank

Fill the reservoir with up to 1.7 L of cold, preferably filtered water.

The water level should:

• Remain above MIN — 5 oz
• Never exceed MAX — 1.7 L Bella-Pro-Barista-Elite-Espress…

Make sure enough water is present for the blank shot and the espresso extraction.

Choosing the Filter Basket

Use:

• 1-cup basket for one single espresso.
• 2-cup basket for a double espresso or two single espressos at the same time. Bella-Pro-Barista-Elite-Espress… Bella-Pro-Barista-Elite-Espress…

Installing the Filter Basket

1. Insert the basket into the portafilter.
2. Align the basket dimple with the portafilter notch.
3. Rotate the basket left or right to lock it.
4. Let the basket cool before attempting to remove it. Bella-Pro-Barista-Elite-Espress…

Locking the Portafilter Into the Brew Head

1. Align the portafilter handle with the INSERT marking.
2. Lift the portafilter into the brew head.
3. Turn the handle counter-clockwise toward the right.
4. Continue until the handle faces forward and sits perpendicular to the machine.
5. Check that the portafilter is firmly sealed and locked. Bella-Pro-Barista-Elite-Espress…

The diagrams on page 8 show the correct filter-basket installation and the movement used to lock the portafilter.

Running the Blank Shot

1. Place a cup under the two portafilter spouts.
2. Press POWER.
3. Wait until all four control-panel buttons are illuminated.
4. Press Single or Double.
5. Hot water runs through the empty portafilter and preheats the brewing components.
6. The flow stops automatically. Bella-Pro-Barista-Elite-Espress…

Adding and Tamping Ground Espresso

After the blank shot:

1. Unlock and remove the portafilter.
2. Add ground espresso with the 2-in-1 tamper spoon.
3. Use the correct filter basket for the desired serving.
4. Tamp the coffee gently and evenly.
5. Keep the tamper dry.
6. Wipe loose coffee grounds from the rim before reinstalling the portafilter. Bella-Pro-Barista-Elite-Espress…

The manual warns that wet spots during tamping can contribute to channeling.

For a double espresso, fill the basket before tamping. Tamping between separate measures can create a layer that interferes with extraction. Bella-Pro-Barista-Elite-Espress…

Brewing a Single Espresso

1. Lock the prepared portafilter into the brew head.
2. Put a cup beneath the spouts.
3. Press SINGLE once.
4. The machine dispenses approximately 1.35 oz.
5. Extraction stops automatically. Bella-Pro-Barista-Elite-Espress…

Brewing a Double Espresso

1. Use the 2-cup filter basket.
2. Lock the portafilter securely.
3. Position one larger cup or two small espresso cups under the spouts.
4. Press DOUBLE once.
5. The machine dispenses approximately 2.7 oz before stopping automatically. Bella-Pro-Barista-Elite-Espress…

Removing the Portafilter After Brewing

Do not remove the portafilter during extraction or while a control-panel button is flashing.

After brewing has finished:

1. Turn the handle clockwise toward the left to unlock it.
2. Lower the portafilter from the brew head.
3. Remove the filter basket after it has cooled.
4. Discard the used coffee puck.
5. Rinse the portafilter and basket. Bella-Pro-Barista-Elite-Espress… Bella-Pro-Barista-Elite-Espress…

How to Program the Single Shot Volume

The factory single-shot setting is approximately 1.35 oz, but the quantity can be changed.

1. Put a cup beneath the portafilter.
2. Press and hold the SINGLE button for 3 seconds.
3. Water/espresso begins to flow.
4. Keep the button held while the desired quantity is dispensed.
5. Release the button when the preferred amount has been reached.
6. The machine stores the new single-shot volume for later brewing. Bella-Pro-Barista-Elite-Espress…

The maximum programmable single-shot volume is 100 mL. Bella-Pro-Barista-Elite-Espress…

How to Program the Double Shot Volume

Use the same process with the DOUBLE button:

1. Hold DOUBLE for approximately 3 seconds.
2. Let extraction begin.
3. Release the button at the desired volume.
4. The new amount is stored for future double-shot operation. Bella-Pro-Barista-Elite-Espress…

The maximum programmable double-shot volume is 150 mL. Bella-Pro-Barista-Elite-Espress…

Reset Shot Volumes to Factory Settings

To restore the original single- and double-shot quantities:

1. Put the machine in standby mode.
2. Press and hold SINGLE and DOUBLE together for 3 seconds.
3. Both indicator lights flash five times.
4. The machine returns to standby with the factory volumes restored. Bella-Pro-Barista-Elite-Espress…

How to Texture and Froth Milk

The steam wand can be used for cappuccino, latte, flat white and other milk-based espresso drinks.

Prepare the Milk

The manual recommends:

• Starting with a cold frothing jug.
• Filling it no more than one-third full.
• Using fresh, cold milk.
• Using skim milk when maximum frothing is desired. Bella-Pro-Barista-Elite-Espress…

Milk expands significantly during steaming, so the jug should not be overfilled.

Step 1: Enter Steam Mode

Press STEAM.

The button flashes while the machine heats and becomes solid once the required steam temperature has been reached. Bella-Pro-Barista-Elite-Espress…

Step 2: Purge Water From the Wand

1. Position the steam wand over the drip tray.
2. Turn the function dial to STEAM.
3. Wait until steam, rather than water, exits.
4. Return the dial to STANDBY. Bella-Pro-Barista-Elite-Espress…

Step 3: Position the Steam Wand

Move the steam-wand tip to the surface of the milk.

The manual recommends:

• Holding the pitcher at an angle.
• Positioning the wand approximately 1/3 inch from the edge of the pitcher.
• Keeping the wand just at the milk’s surface so it creates fine microbubbles. Bella-Pro-Barista-Elite-Espress…

Step 4: Texture the Milk

Turn the dial to STEAM and move the milk in a circular motion.

Continue until:

• The desired milk volume is reached.
• Temperature reaches about 140-150°F for normal hot milk.
• Temperature reaches about 160°F when extra-hot milk is preferred. Bella-Pro-Barista-Elite-Espress…

Step 5: Stop Steaming

Turn the function control dial back to STANDBY before removing the pitcher from the wand. Bella-Pro-Barista-Elite-Espress…

Step 6: Finish the Milk Texture

After steaming:

1. Swirl the milk in the pitcher.
2. Tap the pitcher on the counter.
3. Continue until the milk looks glossy and only a few visible bubbles remain.
4. Pour the textured milk promptly into the espresso. Bella-Pro-Barista-Elite-Espress…

Cleaning the Steam Wand After Every Use

Milk residue should not be allowed to remain on or inside the steam wand.

After steaming:

1. Wipe the wand with a wet kitchen towel.
2. Use the silicone tab to move the hot wand safely.
3. Position it over the drip tray.
4. Turn the control dial to STEAM for several seconds to purge the inside.
5. Return the dial to the off/standby position. Bella-Pro-Barista-Elite-Espress…

Brewing Espresso After Frothing Milk

The boiler is hotter after steam operation than it is during espresso extraction.

If Single and Double flash quickly when a coffee button is pressed after frothing:

1. Turn the function dial to HOT WATER.
2. Position the steam wand over the drip tray, cup or pitcher.
3. Allow hot water to flow.
4. Wait while the machine cools.
5. When the pump stops and the Single, Double and Steam indicators begin flashing, return the dial to OFF.
6. The machine returns to normal standby temperature and espresso can be brewed. Bella-Pro-Barista-Elite-Espress…

Hot Water Function

The steam wand also dispenses hot water.

How to Dispense Hot Water

1. Put the machine in standby.
2. Position a container under the steam wand.
3. Turn the function dial to the HOT WATER / WATER position.
4. Hot water begins flowing.
5. Return the dial to OFF when enough water has been dispensed. Bella-Pro-Barista-Elite-Espress… Bella-Pro-Barista-Elite-Espress…

The hot-water function has a maximum continuous operating time of 1 minute. Bella-Pro-Barista-Elite-Espress…

Steam Maximum Operating Time

The steam function has a maximum continuous working time of approximately:

1.5 minutes Bella-Pro-Barista-Elite-Espress…

Automatic Shutoff

If the machine remains in standby and no controls are used, it automatically switches off after approximately:

30 minutes Bella-Pro-Barista-Elite-Espress…

Indicator Lights Flashing Together

If the machine is turned on and the:

• Single light
• Double light
• Steam light

all flash together, the steam/function dial is not in its OFF position.

Rotate the knob to OFF before trying to use the machine. Bella-Pro-Barista-Elite-Espress…

The same behavior is described when the function knob is already in STEAM before POWER is switched on. Bella-Pro-Barista-Elite-Espress…

Care and Cleaning

Always switch the machine off, return the control to standby, unplug it and allow it to cool completely before cleaning.

The main espresso-maker body must never be submerged in water or another liquid. Bella-Pro-Barista-Elite-Espress…

Cleaning the Portafilter and Filter Baskets

The portafilter and filter basket should be cleaned after every use.

1. Unlock the portafilter.
2. Remove the filter basket.
3. Discard the coffee puck.
4. Rinse the portafilter and filter basket immediately with warm water.
5. Remove remaining coffee oils.
6. If needed, clean with a kitchen brush or soak the basket in cleaning solution for approximately 20 minutes.
7. Rinse and dry completely. Bella-Pro-Barista-Elite-Espress…

Using the Cleaning Pin

The included cleaning pin has different ends for clearing small openings.

The manual directs owners to use it to:

• Clear holes in the filter baskets.
• Clean the steam wand.
• Clear the water-dispenser outlet. Bella-Pro-Barista-Elite-Espress…

Cleaning the Steam Wand and Water Dispenser

After frothing milk or dispensing water:

1. Remove the water-dispenser and frothing tips.
2. Clean them thoroughly.
3. Use the larger end of the cleaning pin to clear the outlets.
4. Rinse the tips.
5. Screw them back onto the appropriate wands securely. Bella-Pro-Barista-Elite-Espress…

Cleaning the Drip Tray

1. Lift off the drip plate.
2. Slide the drip tray straight out.
3. Empty collected water.
4. Wipe the tray dry.
5. Reassemble it. Bella-Pro-Barista-Elite-Espress…

Cleaning the Exterior

Wipe the outside of the machine and the brew head with a damp cloth.

Do not use solvents or detergents that could scratch or damage the machine’s finish. Bella-Pro-Barista-Elite-Espress…

Dishwasher Use

The manual states that no parts of the espresso maker should be cleaned in a dishwasher.

The tamper, filter baskets and drip tray should be washed by hand. Bella-Pro-Barista-Elite-Espress…

Descaling the Espresso Station

Mineral and calcium deposits from hard water can collect inside the machine and affect performance.

The manual recommends descaling with distilled white vinegar approximately every 3 months, although the actual frequency depends on local water conditions and how often the machine is used. Bella-Pro-Barista-Elite-Espress…

Descaling Solution

Prepare:

1 part white vinegar + 3 parts cold water Bella-Pro-Barista-Elite-Espress…

How to Descale

1. Put the control dial in STANDBY.
2. Unplug the machine.
3. Fill the water tank with the vinegar-and-water solution.
4. Install an empty portafilter and filter basket.
5. Put a container beneath the portafilter.
6. Position another container for the steam/hot-water outlet.
7. Plug the machine into a 120V AC outlet.
8. Press POWER.
9. Wait until all four buttons are illuminated.
10. Turn the dial to STEAM.
11. Purge hot steam through the line for at least 45 seconds.
12. Use the Double Shot button repeatedly to pump the descaling solution through the machine.
13. In hard-water areas, repeat the procedure if necessary.
14. Remove the water tank after descaling.
15. Fill it with fresh, cold water.
16. Repeat the flushing process to rinse the internal system thoroughly. Bella-Pro-Barista-Elite-Espress…

The water tank should not be allowed to become completely empty during descaling. Bella-Pro-Barista-Elite-Espress…

Storage Instructions

Before storing the machine:

1. Unplug it.
2. Allow it to cool fully.
3. Clean and dry it.
4. Do not place stress on the power cord where it enters the appliance.
5. Store the Espresso Station in its box or another clean, dry location. Bella-Pro-Barista-Elite-Espress…

Never store the appliance while it is hot or connected to electrical power.

BELLA PRO Barista Elite Troubleshooting

Coffee Runs Down the Side of the Portafilter

Bella-Pro-Barista-Elite-Espress…

Espresso Is Not Coming Out

Possible causes include:

• Empty water tank
• Incorrectly installed water tank
• Blocked brewing system
• Blocked filter basket
• Coffee ground too finely
• Coffee tamped too firmly Bella-Pro-Barista-Elite-Espress…

Recommended actions:

1. Fill the tank.
2. Press the water tank firmly into position.
3. Descale if the brewing system is restricted.
4. Remove and rinse the filter basket.
5. Clear blocked basket holes with the cleaning pin.
6. Wipe the brew head.
7. Try a coarser grind.
8. Tamp with less pressure. Bella-Pro-Barista-Elite-Espress…

Espresso Has Little or No Crema

The troubleshooting table lists these possible causes:

• Coffee is old or dry.
• Grounds are not tamped firmly enough.
• Grind is too coarse.
• Coffee dose is too small. Bella-Pro-Barista-Elite-Espress…

Possible corrections include:

• Use freshly roasted and freshly ground coffee.
• Store coffee in an airtight container.
• Increase tamping pressure.
• Use a finer grind.
• Increase the dose.

Espresso Is Too Cold

Possible causes include:

• Cold cups
• Cold portafilter
• Cold filter basket
• Grind that is too coarse Bella-Pro-Barista-Elite-Espress…

The manual recommends running a blank shot to preheat the cups, portafilter and baskets before extraction.

No Steam Comes From the Steam Wand

The steam nozzle may be blocked.

Clean the steam wand following the Care & Cleaning procedure and clear the outlet with the cleaning pin. Bella-Pro-Barista-Elite-Espress…

Milk Does Not Froth Properly

Possible causes and corrections include:

Bella-Pro-Barista-Elite-Espress…

Two Cups Fill Unevenly

Possible causes include:

• Uneven tamping.
• A blocked portafilter spout.

Make sure the grounds are evenly tamped and both outlets are clear. Bella-Pro-Barista-Elite-Espress…

Espresso Tastes Burnt

The manual gives two possible causes:

1. The coffee itself may not suit the desired taste.
2. The machine may not have been rinsed fully after descaling. Bella-Pro-Barista-Elite-Espress…

Try another coffee, or flush a full tank of clean water through the machine after descaling before brewing again.

Pump Makes an Unusually Loud Noise

Check the water supply first.

Possible causes are:

• Water level below the MIN mark.
• Empty water tank.
• Water tank not seated correctly. Bella-Pro-Barista-Elite-Espress…

Fill the reservoir above the 5 oz MIN level and press the tank firmly into position.

Never operate the espresso maker with an empty water tank.

Espresso Machine Does Not Operate

The troubleshooting table identifies:

• A blocked portafilter/brew head.
• Scale buildup inside the machine. Bella-Pro-Barista-Elite-Espress…

Clean the portafilter and brew head and descale the machine when necessary.

Espresso Drink Recipes

The official manual includes several serving ideas. Bella-Pro-Barista-Elite-Espress…

Short Black

A single espresso topped with a stable layer of crema. Bella-Pro-Barista-Elite-Espress…

Flat White

A single espresso with steamed milk, using approximately:

• 1/3 coffee
• 2/3 steamed milk Bella-Pro-Barista-Elite-Espress…

Americano or Long Black

A standard espresso diluted with hot water.

The manual recommends adding the hot water before the espresso to help preserve the crema. Bella-Pro-Barista-Elite-Espress…

Café Latte

A single espresso with steamed milk. The manual recommends a top microbubble layer of about 10 mm. Bella-Pro-Barista-Elite-Espress…

Cappuccino

Espresso with steamed milk, creamy froth and a dusting of chocolate.

The manual describes the finished drink as approximately:

• 2/3 milky coffee
• 1/3 microbubbles Bella-Pro-Barista-Elite-Espress…

Café Mocha

Prepared similarly to cappuccino, with drinking chocolate mixed into the espresso before adding milk and foam. The manual suggests whipped cream on top. Bella-Pro-Barista-Elite-Espress…

Macchiato

A short or long espresso served with a small amount of milk or a small spoonful of foam in the center of the crema. Bella-Pro-Barista-Elite-Espress…

Yuan Yang Coffee With Tea

The manual’s recipe combines:

• 4 small black tea bags
• One 14 oz can sweetened condensed milk
• 2 cups Americano coffee Bella-Pro-Barista-Elite-Espress…

Espresso Vodka Cocktail

The recipe uses:

• 1.5 oz vodka
• 1/2 oz fresh lemon juice
• 1/2 oz simple syrup
• 2 single espresso shots
• Ice
• Lemon zest Bella-Pro-Barista-Elite-Espress…

User Maintenance

The Barista Elite Espresso Station contains no user-serviceable internal parts.

Repairs that require disassembly should be carried out by a qualified appliance repair technician. Bella-Pro-Barista-Elite-Espress…

Two-Year Limited Warranty

SENSIO Inc. provides:

• 2-year coverage for mechanical defects in material and workmanship.
• 90-day coverage for non-mechanical parts. Bella-Pro-Barista-Elite-Espress…

During the applicable warranty period, SENSIO may choose to:

• Repair the product.
• Replace the product.
• Issue a refund. Bella-Pro-Barista-Elite-Espress…

The warranty applies to the original retail purchaser and is not transferable. Proof of purchase is required. Bella-Pro-Barista-Elite-Espress…

Warranty Exclusions

The warranty does not cover damage resulting from:

• Normal wear
• Negligent use
• Incorrect voltage or current
• Incorrect routine maintenance
• Use contrary to the operating instructions
• Unauthorized disassembly
• Unauthorized repairs or alterations
• Fire
• Flood
• Hurricane
• Tornado or similar listed events Bella-Pro-Barista-Elite-Espress…

How to Obtain Warranty Service

Contact Customer Service at:

1-866-832-4843

A representative will first try to resolve the issue by phone. If return service is required, a case number and return instructions are provided.

The returned product should include:

• Customer name
• Address
• Daytime telephone number
• Case number
• Description of the problem
• Copy of the original sales receipt Bella-Pro-Barista-Elite-Espress…

Customer Support

The manual lists:

Customer Service Phone: 1-866-832-4843
Email: help@bellahousewares.com
Website: bellakitchenware.com

SENSIO Inc. / Made by Gather
New York, NY 10016, USA Bella-Pro-Barista-Elite-Espress…

Frequently Asked Questions

How do you use the BELLA PRO Barista Elite Espresso Station?

Fill the water tank with cold water above the MIN mark, preheat the machine, run a blank shot, add and tamp espresso into the correct filter basket, lock the portafilter into the brew head and press SINGLE or DOUBLE. The machine stops automatically after dispensing its programmed volume. Bella-Pro-Barista-Elite-Espress… Bella-Pro-Barista-Elite-Espress…

How much water does the BELLA PRO Barista Elite hold?

The removable water tank holds up to 1.7 liters / 57 ounces. The water should remain above the 5 oz MIN mark and never exceed the MAX line. Bella-Pro-Barista-Elite-Espress… Bella-Pro-Barista-Elite-Espress…

How much espresso does the Single button make?

The factory setting dispenses approximately 1.35 oz. The volume can be changed by holding SINGLE for three seconds and releasing the button when the preferred amount has been dispensed. Bella-Pro-Barista-Elite-Espress… Bella-Pro-Barista-Elite-Espress…

How much espresso does the Double button make?

The factory-set double shot is approximately 2.7 oz. Its stored volume can also be changed by holding the DOUBLE button for three seconds during programming. Bella-Pro-Barista-Elite-Espress… Bella-Pro-Barista-Elite-Espress…

How do you reset the single and double shot volumes?

With the machine in standby, hold SINGLE and DOUBLE together for 3 seconds. Their lights flash five times when the factory volumes have been restored. Bella-Pro-Barista-Elite-Espress…

Why are the Single, Double and Steam lights flashing together?

This indicates that the function/steam knob is not in the OFF position. Rotate the dial back to OFF before using the machine. Bella-Pro-Barista-Elite-Espress…

Why is no espresso coming out of the BELLA PRO espresso machine?

Check for an empty or incorrectly installed water tank, blocked filter basket, excessive tamping, coffee that is ground too finely or mineral buildup. Clean the filter and brew head, use the cleaning pin when required, try a coarser grind and descale the machine when necessary. Bella-Pro-Barista-Elite-Espress…

How often should the BELLA PRO Barista Elite be descaled?

The manual recommends descaling with a mixture of 1 part white vinegar to 3 parts cold water approximately every 3 months, with frequency adjusted for local water hardness and how often the machine is used. Bella-Pro-Barista-Elite-Espress…
